DiskStation Plus · DS1525+

Synology DiskStation DS1525+ 5-bay NAS

Name: Synology DiskStation DS1525+ 5-bay NAS
Brand: Synology
SKU: DS1525+
Price: 2499.00 AUD
Availability: InStock

Versatile all-purpose data hub

$2,499.00inc. GST

Only 2 left

Sold diskless. Add compatible drives below and we will ship everything together.

Australian stock, GST tax invoice
Genuine Synology, full local warranty
Dispatched in 1 business day when in stock
Ask a question about this model

Processor: AMD Ryzen V1500B
Memory: 8 GB DDR4 ECC SODIMM
Bays: 5 × 3.5" SATA HDD or 2.5" SATA SSD 2 × M.2 2280 NVMe SSD
Max bays with expansion: 15 (DX525 × 2)
2.5GbE LAN ports: 2

Data sheet and downloads on synology.com

About the DS1525+

Synology DS1525+ is a versatile 5-bay storage solution that scales with your needs, with support for storage expansion,1 10GbE networking,2 and SSD caching3. Built-in 2.5GbE networking provides excellent networking performance out of the box. Powered by Synology DiskStation Manager (DSM), this device is a flexible all-in-one solution for data sharing, synchronization, backup, and surveillance.

Key points

5-bay desktop NAS
AMD Ryzen V1500B 4-core / 8-thread processor
8 GB DDR4 ECC SODIMM memory (expandable to 32 GB)
Dual 2.5GbE RJ-45 network ports
Supports SSD cache and M.2 NVMe SSD storage pools
Two built-in M.2 2280 NVMe SSD slots
Expandable up to 15 drive bays with Synology DX525 expansion units
Supports up to 200 TB single volume capacity

Specifications

As published by Synology for the DS1525+. Confirm the latest data sheet before relying on a figure for a tender.

CPU
CPU Model	AMD Ryzen V1500B
CPU Quantity	1
CPU Cores	4
CPU Threads	8
CPU Architecture	64-bit
CPU Frequency	2.2 GHz
Memory
System Memory	8 GB DDR4 ECC SODIMM
Memory Module Pre-installed	8 GB (8 GB × 1)
Total Memory Slots	2
Maximum Memory Capacity	32 GB (16 GB × 2)
Storage
Drive Bays	5 × 3.5" SATA HDD or 2.5" SATA SSD 2 × M.2 2280 NVMe SSD
Maximum Drive Bays with Expansion Unit	15 (DX525 × 2)
External Ports
RJ-45 2.5GbE LAN Port	2
USB 3.2 Gen 1 Port	2
Expansion Port	2
Expansion Port Type	USB Type-C
PCIe
PCIe Expansion	1 × Gen3 x2 network upgrade slot
Appearance
Size (Height × Width × Depth)	166 mm × 230 mm × 223 mm
Weight	2.67 kg
Others
System Fan	92 mm × 92 mm × 2 pcs
Fan Speed Mode	Full-Speed Mode Cool Mode Quiet Mode
Noise Level	22.60 dB(A)
Power Supply Unit / Adapter	120 watts
AC Input Power Voltage	100V to 240V AC
Power Frequency	50/60 Hz, Single Phase
Power Consumption	44.56 watts (Access) 13.63 watts (HDD Hibernation)
British Thermal Unit	151.95 BTU/hr (Access) 46.48 BTU/hr (HDD Hibernation)
Temperature
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20°C to 60°C (-5°F to 140°F)
Operating Humidity	8% to 80% RH
Storage Humidity	5% to 95% RH
Certification
	FCC CE BSMI VCCI RCM UKCA EAC CCC KC BIS
Warranty
	3-year hardware warranty, extendable to 5 years with
Environment
	RoHS Compliant
Packaging Content
	Main Unit × 1 Accessory Pack × 1 AC Power Adapter × 1 AC Power Cord × 1 RJ-45 LAN Cable × 2
Optional Accessories
	DDR4 ECC SODIMM: / Expansion Units: Enterprise Series 3.5" SATA HDD: Plus Series 3.5" SATA HDD: Enterprise Series 2.5" SATA SSD: Enterprise Series M.2 2280 NVMe SSD: 10GbE Network Upgrade Module:

Shipping

In-stock items leave our Australian warehouse within one business day. Order-in items usually arrive in 3 to 7 business days from the distributor. Shipping is calculated at checkout from the weight of your order (this item: 7.2 kg).

Shipping details

Warranty

Genuine Australian stock with Synology's manufacturer warranty, serviced locally. Most Plus and xs+ models carry a three or five year warranty and are eligible for EW201/EW202 extension.

Returns and warranty
