Synology DS1525NEO+ DDR4 memory module
Versatile all-purpose data hub
$1,829.00inc. GST
In stock, 15 available
- Australian stock, GST tax invoice
- Genuine Synology, full local warranty
- Dispatched in 1 business day when in stock
- Ask a question about this model
- Processor
- AMD Ryzen V1500B
- Memory
- 4 GB DDR4 non-ECC SODIMM
- Bays
- 5 × 3.5" SATA HDD or 2.5" SATA SSD 2 × M.2 2280 NVMe SSD
- Max bays with expansion
- 15 (DX525 × 2)
- 2.5GbE LAN ports
- 2
About the DS1525NEO+
Synology DS1525neo+ is a versatile 5-bay storage solution that scales with your needs, with support for storage expansion, 10GbE networking, and SSD caching. Built-in 2.5GbE networking provides excellent networking performance out of the box. Powered by Synology DiskStation Manager (DSM), this device is a flexible all-in-one solution for data sharing, synchronization, backup, and surveillance.
Key points
- Drive Bays 5 × 3.5" SATA HDD or 2.5" SATA SSD 2 × M.2 2280 NVMe SSD
- Expandable up to 15 drive bays with Synology DX525 expansion units
- Supports up to 360 TB raw capacity (with expansion)
Specifications
As published by Synology for the DS1525NEO+. Confirm the latest data sheet before relying on a figure for a tender.
| CPU | |
|---|---|
| CPU Model | AMD Ryzen V1500B |
| CPU Quantity | 1 |
| CPU Cores | 4 |
| CPU Threads | 8 |
| CPU Architecture | 64-bit |
| CPU Frequency | 2.2 GHz |
| Memory | |
| System Memory | 4 GB DDR4 non-ECC SODIMM |
| Memory Module Pre-installed | 4 GB (4 GB × 1) |
| Total Memory Slots | 2 |
| Maximum Memory Capacity | 32 GB (16 GB × 2) |
| Storage | |
| Drive Bays | 5 × 3.5" SATA HDD or 2.5" SATA SSD 2 × M.2 2280 NVMe SSD |
| Maximum Drive Bays with Expansion Unit | 15 (DX525 × 2) |
| External Ports | |
| RJ-45 2.5GbE LAN Port | 2 |
| USB 3.2 Gen 1 Port | 2 |
| Expansion Port | 2 |
| Expansion Port Type | USB Type-C |
| PCIe | |
| PCIe Expansion | 1 × Gen3 x2 network upgrade slot |
| Appearance | |
| Size (Height × Width × Depth) | 166 mm × 230 mm × 223 mm |
| Weight | 2.67 kg |
| Others | |
| System Fan | 92 mm × 92 mm × 2 pcs |
| Fan Speed Mode | Full-Speed Mode Cool Mode Quiet Mode |
| Noise Level | 22.60 dB(A) |
| Power Supply Unit / Adapter | 120 watts |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | 44.56 watts (Access) 13.63 watts (HDD Hibernation) |
| British Thermal Unit | 151.95 BTU/hr (Access) 46.48 BTU/hr (HDD Hibernation) |
| Temperature | |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Operating Humidity | 8% to 80% RH |
| Storage Humidity | 5% to 95% RH |
| Certification | |
| FCC CE BSMI VCCI RCM UKCA EAC CCC KC BIS | |
| Warranty | |
| 3-year hardware warranty, extendable to 5 years with or | |
| Environment | |
| RoHS Compliant | |
| Packaging Content | |
| Main Unit × 1 Accessory Pack × 1 AC Power Adapter × 1 AC Power Cord × 1 RJ-45 LAN Cable × 2 | |
| Optional Accessories | |
| DDR4 non-ECC SODIMM: DDR4 ECC SODIMM: / / Expansion Units: Enterprise Series 3.5" SATA HDD: Plus Series 3.5" SATA HDD: Enterprise Series 2.5" SATA SSD: Enterprise Series M.2 2280 NVMe SSD: 10GbE Network Upgrade Module: | |
Shipping
In-stock items leave our Australian warehouse within one business day. Order-in items usually arrive in 3 to 7 business days from the distributor. Shipping is calculated at checkout from the weight of your order (this item: 7.5 kg).
Shipping detailsWarranty
Genuine Australian stock with Synology's manufacturer warranty, serviced locally. Warranty terms are on the Synology data sheet for this model.
Returns and warrantyNeed a hand?
We will confirm compatibility with your existing NAS, recommend drives and memory, or quote a configured unit for a business site.
Ask belowAsk about the DS1525NEO+
Compatibility, lead times, a quote for several units: a person replies, usually the same business day.
