Memory · DS1825NEO+
Synology DS1825NEO+ DDR4 memory module
High-capacity & versatile storage solution in a desktop form factor
$2,289.00inc. GST
In stock, 7 available
- Australian stock, GST tax invoice
- Genuine Synology, full local warranty
- Dispatched in 1 business day when in stock
- Ask a question about this model
- Processor
- AMD Ryzen V1500B
- Memory
- 4 GB DDR4 non-ECC SODIMM
- Bays
- 8 × 3.5" SATA HDD or 2.5" SATA SSD 2 × M.2 2280 NVMe SSD
- Max bays with expansion
- 18 (DX525 × 2)
- 2.5GbE LAN ports
- 2
About the DS1825NEO+
The DS1825neo+ is a versatile 8-bay storage solution designed to store and protect mission-critical data. Flexible support for faster networking speeds and capacity expansion makes the DS1825neo+ ideal for businesses needing a scalable and customizable storage solution for their growing data needs. Powered by Synology DiskStation Manager (DSM), this device is a flexible all-in-one solution for data sharing, synchronization, backup, and surveillance.
Key points
- Drive Bays
- 8 × 3.5" SATA HDD or 2.5" SATA SSD
- 2 × M.2 2280 NVMe SSD
- Expandable up to 18 drive bays with Synology DX525 expansion units
- Supports up to 432 TB raw capacity (with expansion)
Specifications
As published by Synology for the DS1825NEO+. Confirm the latest data sheet before relying on a figure for a tender.
| CPU | |
|---|---|
| CPU Model | AMD Ryzen V1500B |
| CPU Quantity | 1 |
| CPU Cores | 4 |
| CPU Threads | 8 |
| CPU Architecture | 64-bit |
| CPU Frequency | 2.2 GHz |
| Memory | |
| System Memory | 4 GB DDR4 non-ECC SODIMM |
| Memory Module Pre-installed | 4 GB (4 GB × 1) |
| Total Memory Slots | 2 |
| Maximum Memory Capacity | 32 GB (16 GB × 2) |
| Storage | |
| Drive Bays | 8 × 3.5" SATA HDD or 2.5" SATA SSD 2 × M.2 2280 NVMe SSD |
| Maximum Drive Bays with Expansion Unit | 18 (DX525 × 2) |
| External Ports | |
| RJ-45 2.5GbE LAN Port | 2 |
| USB 3.2 Gen 1 Port | 3 |
| Expansion Port | 2 |
| Expansion Port Type | USB Type-C |
| PCIe | |
| PCIe Expansion | 1 × Gen3 x8 slot (x4 link) |
| Appearance | |
| Size (Height × Width × Depth) | 166 mm × 343 mm × 243 mm |
| Weight | 6 kg |
| Others | |
| System Fan | 120 mm × 120 mm × 2 pcs |
| Fan Speed Mode | Full-Speed Mode Cool Mode Quiet Mode |
| Noise Level | 23.8 dB(A) |
| Power Supply Unit / Adapter | 250 watts |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | 60.1 watts (Access) 18.34 watts (HDD Hibernation) |
| British Thermal Unit | 204.94 BTU/hr (Access) 62.54 BTU/hr (HDD Hibernation) |
| Temperature | |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Operating Humidity | 8% to 80% RH |
| Storage Humidity | 5% to 95% RH |
| Certification | |
| FCC CE BSMI VCCI RCM UKCA EAC CCC KC BIS | |
| Warranty | |
| 3-year hardware warranty, extendable to 5 years with or | |
| Environment | |
| RoHS Compliant | |
| Packaging Content | |
| Main Unit × 1 Accessory Pack × 1 AC Power Cord × 1 RJ-45 LAN Cable × 2 | |
| Optional Accessories | |
| DDR4 non-ECC SODIMM: DDR4 ECC SODIMM: / / Expansion Units: Enterprise Series 3.5" SATA HDD: Plus Series 3.5" SATA HDD: Enterprise Series 2.5" SATA SSD: Enterprise Series M.2 2280 NVMe SSD: 25GbE Network Interface Card: 10GbE Network Interface Card: / / | |
