Synology RackStation RS11626XS+ 16-bay rackmount NAS

Name: Synology RackStation RS11626XS+ 16-bay rackmount NAS
Brand: Synology
SKU: RS11626XS+
Price: 19999.00 AUD
Availability: OutOfStock

Powerful enterprise storage for mission-critical data environments

$19,999.00inc. GST

Out of stock

Ask about availability

Sold diskless. Add compatible drives below and we will ship everything together.

Australian stock, GST tax invoice
Genuine Synology, full local warranty
Dispatched in 1 business day when in stock
Ask a question about this model

Processor: AMD EPYC 7303
Memory: 64 GB DDR4 ECC RDIMM
Bays: 16 × 3.5" SATA HDD or 2.5" SATA SSD 4 × 2.5" SATA SSD
Max bays with expansion: 116 (RX1222sas × 8)
10GbE LAN ports: 2
Form Factor: 3U

Data sheet and downloads on synology.com

About the RS11626XS+

The RS11626xs+ unifies data management, backup, and surveillance in a storage system scalable beyond 2 PB. It includes four built-in 2.5" bays for SSD caching and dual embeddedM.2 NVMe SSDs running DSM in RAID 1,providing redundancy and offloading systemactivity from the data pool. A comprehensive set of reliability, availability, and serviceability features ensures continuous operation

Key points

16 bays support 3.5" SATA HDDs or 2.5" SATA SSDs; the additional 4 bays are for 2.5" SATA SSDs.
AMD EPYC 7303 16-core / 32-thread processor
64 GB DDR4 ECC RDIMM memory (expandable to 1 TB)
Up to 10,500 / 8,200 MB/s sequential read/write throughput
Dual built-in 10GbE RJ-45 network ports
Expandable up to 116 drive bays with Synology RX1222sas expansion units

Specifications

As published by Synology for the RS11626XS+. Confirm the latest data sheet before relying on a figure for a tender.

CPU
CPU Model	AMD EPYC 7303
CPU Quantity	1
CPU Cores	16
CPU Threads	32
CPU Architecture	64-bit
CPU Frequency	2.4 (base) / 3.4 (turbo) GHz
Memory
System Memory	64 GB DDR4 ECC RDIMM
Memory Module Pre-installed	64 GB (64 GB × 1)
Total Memory Slots	16
Maximum Memory Capacity	1024 GB (64 GB × 16)
Storage
Drive Bays	16 × 3.5" SATA HDD or 2.5" SATA SSD 4 × 2.5" SATA SSD
Maximum Drive Bays with Expansion Unit	116 (RX1222sas × 8)
System Drive	2 × M.2 NVMe SSD (pre-installed)
External Ports
RJ-45 10GbE LAN Port	2
Out-of-Band Management LAN Port	1
USB 3.2 Gen 1 Port	2
Expansion Port	8
Expansion Port Type	Mini-SAS HD
PCIe
PCIe Expansion	2 × Gen4 x16 slot (x16 link)
Appearance
Form Factor (RU)	3U
Size (Height × Width × Depth)	132.3 mm × 482 mm × 724 mm
Weight	19.68 kg
Rack Installation Support	4-post 19" rack (Synology Rail Kit - )
Others
System Fan	80 mm × 80 mm × 4 pcs
Fan Speed Mode	Full-Speed Mode Cool Mode Quiet Mode
Noise Level	52.9 dB(A)
Power Supply Unit / Adapter	800 watts
AC Input Power Voltage	100V to 240V AC
Power Frequency	50/60 Hz, Single Phase
Power Consumption	238.4 watts (Access) 127.26 watts (HDD Hibernation)
British Thermal Unit	812.94 BTU/hr (Access) 433.96 BTU/hr (HDD Hibernation)
Temperature
Operating Temperature	0°C to 35°C (32°F to 95°F)
Storage Temperature	-20°C to 60°C (-5°F to 140°F)
Operating Humidity	8% to 80% RH
Storage Humidity	5% to 95% RH
Warranty
Optional Accessories

Maximum Single Volume Size	1 PB (for RAID 6 groups only) 200 TB 108 TB
Maximum Internal Volume Number	32
Supported RAID Type	RAID F1 Basic JBOD RAID 0 RAID 1 RAID 5 RAID 6 RAID 10
RAID Migration	Basic to RAID 1 Basic to RAID 5 RAID 1 to RAID 5 RAID 5 to RAID 6
Volume Expansion with Larger HDDs	RAID F1 RAID 1 RAID 5 RAID 6 RAID 10
Volume Expansion by Adding a HDD	RAID F1 JBOD RAID 5 RAID 6
Global Hot Spare Supported RAID Type	RAID F1 RAID 1 RAID 5 RAID 6 RAID 10

Internal Drives	Btrfs
External Drives	Btrfs ext4 ext3 FAT32 NTFS HFS+ exFAT

File Protocol	SMB AFP NFS FTP WebDAV Rsync
Maximum Number of SMB Connections (FSCT-Based)	10,000

Maximum Local User Accounts	15,360
Maximum Local Groups	512
Maximum Shared Folder	512
Maximum Shared Folder Sync Tasks	32

Hybrid Share Folder Number	30

Syslog Events per Second	3,000
Virtualization
VMware vSphere	ESXi 8.0 U2, ESXi 8.0 U1, ESXi 8.0, ESXi 7.0 U3, ESXi 7.0 U2, ESXi 7.0 U1, ESXi 7.0, ESXi 6.7 U3, ESXi 6.7 U2, ESXi 6.7 U1, ESXi 6.7, ESXi 6.5 U3, ESXi 6.5 U2, ESXi 6.5 U1, ESXi 6.5
Microsoft Hyper-V	Windows Server 2025, Windows Server 2022
Citrix XenServer	XenServer 8.4, XenServer 8, Citrix Hypervisor 8.2 LTSR CU1
OpenStack	Cinder

Supported Protocols	SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Supported Browsers	Chrome Firefox Edge Safari
Supported Language	English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文
Synology AI Console
Maximum De-Identification Rate	12,000 words per second

Maximum Number of Users	1,500
Download Station
Maximum Concurrent Download Tasks	80

Maximum iSCSI Target Number	256
Maximum LUN	512

Free Email Accounts	5
Maximum Number of Users	25,000

Maximum Snapshots per Shared Folder	1,024
Maximum Snapshots per LUN	256
Maximum Snapshots per System	65,536
Maximum Replication Tasks for Shared Folders	128
Maximum Replication Tasks for LUNs	64
Maximum Replication Tasks per System	128

Default Licenses	2
Maximum IP Cameras and Total FPS (H.264)	1080p: 400 channels, 4000 FPS 3M: 300 channels, 3000 FPS 5M: 200 channels, 2000 FPS 4K: 150 channels, 1500 FPS
Maximum IP Cameras and Total FPS (H.265)	1080p: 450 channels, 13500 FPS 3M: 400 channels, 4000 FPS 5M: 300 channels, 3000 FPS 4K: 200 channels, 2000 FPS

Maximum Number of Users	37,300
Maximum Number of Hosted Files	100,000,000 (applies to files indexed or hosted by . For file access through other standard protocols, refer to the File Services section above)

Maximum Number of Users	36,200

Recommended Virtual Machine Instances	32
Recommended Virtual DSM Number	32 (including 1 Free License)

Maximum Connections	32
