Synology RackStation RS1226+ 8-bay rackmount NAS

Name: Synology RackStation RS1226+ 8-bay rackmount NAS
Brand: Synology
SKU: RS1226+
Price: 3599.00 AUD
Availability: InStock

$3,599.00inc. GST

In stock, 6 available

Sold diskless. Add compatible drives below and we will ship everything together.

Australian stock, GST tax invoice
Genuine Synology, full local warranty
Dispatched in 1 business day when in stock
Ask a question about this model

Processor: AMD Ryzen V1500B
Memory: 4 GB DDR4 ECC SODIMM
Bays: 8 × 3.5" SATA HDD or 2.5" SATA SSD 2 × M.2 2280 NVMe SSD
Max bays with expansion: 12 (RX426 × 1)
2.5GbE LAN ports: 2
Form Factor: 2U

Data sheet and downloads on synology.com

About the RS1226+

Synology RackStation RS1226+ is a versatile and reliable 2U 8-bay storage system with built-in dual M.2 slots, ideal for small to medium sized businesses and branch offices that depend on 24/7 data service. Powered by Synology DiskStation Manager (DSM), this system streamlines data backups, file sharing and synchronizing, productivity applications, and other essential office applications. Project support available! Enquire with MMT New DSM Installs are locked to Synology drives

Key points

8-bay 2U rackmount NAS
AMD Ryzen V1500B 4-core / 8-thread processor
4 GB DDR4 ECC SODIMM memory (expandable to 32 GB)
Dual 2.5GbE RJ-45 network ports
Supports SSD cache and M.2 NVMe SSD storage pools
Two built-in M.2 2280 NVMe SSD slots
Expandable up to 12 drive bays with Synology RX426 expansion unit
Supports up to 200 TB single volume capacity

Specifications

As published by Synology for the RS1226+. Confirm the latest data sheet before relying on a figure for a tender.

CPU
CPU Model	AMD Ryzen V1500B
CPU Quantity	1
CPU Cores	4
CPU Threads	8
CPU Architecture	64-bit
CPU Frequency	2.2 GHz
Memory
System Memory	4 GB DDR4 ECC SODIMM
Memory Module Pre-installed	4 GB (4 GB × 1)
Total Memory Slots	2
Maximum Memory Capacity	32 GB (16 GB × 2)
Storage
Drive Bays	8 × 3.5" SATA HDD or 2.5" SATA SSD 2 × M.2 2280 NVMe SSD
Maximum Drive Bays with Expansion Unit	12 (RX426 × 1)
External Ports
RJ-45 2.5GbE LAN Port	2
USB 3.2 Gen 1 Port	2
Expansion Port	1
Expansion Port Type	USB Type-C
PCIe
PCIe Expansion	1 × Gen3 x8 slot (x4 link)
Appearance
Form Factor (RU)	2U
Size (Height × Width × Depth)	88 mm × 482 mm × 306.6 mm
Weight	6.8 kg
Rack Installation Support	4-post 19" rack (Synology Rail Kit - / ) 2-post 19" rack (direct mounting)
Others
System Fan	80 mm × 80 mm × 2 pcs
Fan Speed Mode	Full-Speed Mode Cool Mode Quiet Mode
Noise Level	23.3 dB(A)
Power Supply Unit / Adapter	250 watts
AC Input Power Voltage	100 V to 240 V AC
Power Frequency	50/60 Hz, Single Phase
Power Consumption	72.33 watts (Access) 20.74 watts (HDD Hibernation)
British Thermal Unit	246.97 BTU/hr (Access) 70.82 BTU/hr (HDD Hibernation)
Temperature
Operating Temperature	0°C to 35°C (32°F to 95°F)
Storage Temperature	-20°C to 60°C (-5°F to 140°F)
Operating Humidity	8% to 80% RH
Storage Humidity	5% to 95% RH
Certification
	FCC CE BSMI VCCI RCM UKCA EAC CCC KC BIS UL
Warranty
	3-year hardware warranty, extendable to 5 years with
Environment
	RoHS Compliant
Packaging Content
	Main Unit × 1 Accessory Pack × 1 AC Power Cord × 1 C13 to C14 power cord × 1
Optional Accessories
	DDR4 ECC SODIMM: / / Expansion Units: Enterprise Series 3.5" SATA HDD: Plus Series 3.5" SATA HDD: Enterprise Series 2.5" SATA SSD: Enterprise Series M.2 2280 NVMe SSD: 25GbE Network Interface Card: 10GbE Network Interface Card: / / Rail Kit Sliding: Rail Kit Mounted:
