Synology RackStation RS2423RP+II 12-bay rackmount NAS

Name: Synology RackStation RS2423RP+II 12-bay rackmount NAS
Brand: Synology
SKU: RS2423RP+II
Price: 6999.00 AUD
Availability: InStock

Efficient storage for centralized data management

$6,999.00inc. GST

Only 3 left

Sold diskless. Add compatible drives below and we will ship everything together.

Australian stock, GST tax invoice
Genuine Synology, full local warranty
Dispatched in 1 business day when in stock
Ask a question about this model

Processor: AMD Ryzen V1780B
Memory: 8 GB DDR4 ECC UDIMM
Bays: 12 × 3.5" SATA HDD or 2.5" SATA SSD
Max bays with expansion: 24 (RX1223RP × 1)
1GbE LAN ports: 2
10GbE LAN ports: 1

Data sheet and downloads on synology.com

Key points

Hardware Overview
CPU: AMD Ryzen V1780B, 4 cores / 8 threads, 3.35 GHz (base) / 3.6 GHz (turbo), 64-bit, with hardware encryption engine
Memory: 8 GB DDR4 ECC UDIMM (expandable up to 32 GB, 2 slots)
Drive Bays: 12 (supports 3.5" SATA HDDs and 2.5" SATA SSDs)
Expandable up to 24 bays with 1x RX1223RP expansion unit
Hot Swappable Drives: Yes
Network Ports: 2 x 1GbE RJ-45, 1 x 10GbE RJ-45
USB Ports: 2 x USB 3.2 Gen 1
PCIe Expansion: 1 x Gen3 x8 slot (x4 link)
Redundant Power Supply: Yes, 550W
Form Factor: 2U rackmount (Synology Rail Kit RKS-02 supported, sold separately)
Dimensions: 88 mm (H) x 482 mm (W) x 578 mm (D)
Weight: 11.9 kg
Storage & RAID

Specifications

As published by Synology for the RS2423RP+II. Confirm the latest data sheet before relying on a figure for a tender.

CPU
CPU Model	AMD Ryzen V1780B
CPU Quantity	1
CPU Cores	4
CPU Threads	8
CPU Architecture	64-bit
CPU Frequency	3.35 (base) / 3.6 (turbo) GHz
Memory
System Memory	8 GB DDR4 ECC UDIMM
Memory Module Pre-installed	8 GB (8 GB × 1)
Total Memory Slots	2
Maximum Memory Capacity	32 GB (16 GB × 2)
Storage
Drive Bays	12 × 3.5" SATA HDD or 2.5" SATA SSD
Maximum Drive Bays with Expansion Unit	24 (RX1223RP × 1)
External Ports
RJ-45 1GbE LAN Port	2
RJ-45 10GbE LAN Port	1
USB 3.2 Gen 1 Port	2
Expansion Port	1
Expansion Port Type	Mini-SAS HD
PCIe
PCIe Expansion	1 × Gen3 x8 slot (x4 link)
Appearance
Form Factor (RU)	2U
Size (Height × Width × Depth)	88 mm × 482 mm × 578 mm
Weight	11.9 kg
Rack Installation Support	4-post 19" rack (Synology Rail Kit - )
Others
System Fan	60 mm × 60 mm × 3 pcs
Fan Speed Mode	Full-Speed Mode Cool Mode Quiet Mode
Noise Level	56.2 dB(A)
Power Supply Unit / Adapter	550 watts
AC Input Power Voltage	100 V to 240 V AC
Power Frequency	50/60 Hz, Single Phase
Power Consumption	114.86 watts (Access) 42.33 watts (HDD Hibernation)
British Thermal Unit	392.18 BTU/hr (Access) 144.53 BTU/hr (HDD Hibernation)
Temperature
Operating Temperature	0°C to 35°C (32°F to 95°F)
Storage Temperature	-20°C to 60°C (-5°F to 140°F)
Operating Humidity	8% to 80% RH
Storage Humidity	5% to 95% RH
Certification
	FCC CE BSMI VCCI RCM UKCA EAC CCC KC BIS UL
Warranty
	3-year hardware warranty, extendable to 5 years with or
Environment
	RoHS Compliant
Packaging Content
	Main Unit × 1 Accessory Pack × 1 AC Power Cord × 2 Quick Installation Guide × 1
Optional Accessories
	DDR4 ECC UDIMM: / Expansion Units: Enterprise Series 3.5" SATA HDD: Plus Series 3.5" SATA HDD: Enterprise Series 2.5" SATA SSD: M.2 SSD & 10GbE Combo Adapter Card: M.2 SSD Adapter Card: 25GbE Network Interface Card: 10GbE Network Interface Card: / / Rail Kit Sliding:

Shipping

In-stock items leave our Australian warehouse within one business day. Order-in items usually arrive in 3 to 7 business days from the distributor. Shipping is calculated at checkout from the weight of your order (this item: 27 kg).

Shipping details

Warranty

Genuine Australian stock with Synology's manufacturer warranty, serviced locally. Most Plus and xs+ models carry a three or five year warranty and are eligible for EW201/EW202 extension.

Returns and warranty
