RackStation XS · RS3626XS

Synology RackStation RS3626XS 12-bay rackmount NAS

Name: Synology RackStation RS3626XS 12-bay rackmount NAS
Brand: Synology
SKU: RS3626XS
Price: 9999.00 AUD
Availability: InStock

Reliable, high-capacity storage for enterprise workloads.

$9,999.00inc. GST

Only 3 left

Sold diskless. Add compatible drives below and we will ship everything together.

Australian stock, GST tax invoice
Genuine Synology, full local warranty
Dispatched in 1 business day when in stock
Ask a question about this model

Processor: Intel Xeon D-1726
Memory: 8 GB DDR4 ECC UDIMM
Bays: 12 × 3.5" SATA HDD or 2.5" SATA SSD
Max bays with expansion: 36 (RX1225RP × 2)
10GbE LAN ports: 2
Form Factor: 2U

Data sheet and downloads on synology.com

About the RS3626XS

The RS3626xs is an all-in-one solution for central data management, backup, and surveillance. Designed to grow with your business, the 2U 12-bay RS3626xs scales up to 36 total drive bays with two RX1225RP 12-bay expansion units, along with versatile networking configurations and SSD caching support. A full suite of reliability, availability, and serviceability features ensures continuous operation.

Key points

12-bay 2U rackmount NAS
Intel Xeon D-1726 6-core / 12-thread processor
8 GB DDR4 ECC UDIMM memory (expandable to 48 GB)
Up to 6,300 / 3,700 MB/s sequential read/write throughput
Built-in dual 10GbE RJ-45 network ports
Supports SSD cache (SATA SSD or M.2 NVMe via adapter)
Expandable up to 36 drive bays with Synology expansion units
Supports up to 864 TB raw capacity (with expansion)

Specifications

As published by Synology for the RS3626XS. Confirm the latest data sheet before relying on a figure for a tender.

CPU
CPU Model	Intel Xeon D-1726
CPU Quantity	1
CPU Cores	6
CPU Threads	12
CPU Architecture	64-bit
CPU Frequency	2.9 (base) / 3.5 (turbo) GHz
Memory
System Memory	8 GB DDR4 ECC UDIMM
Memory Module Pre-installed	8 GB (8 GB × 1)
Total Memory Slots	6
Maximum Memory Capacity	48 GB (8 GB × 6)
Storage
Drive Bays	12 × 3.5" SATA HDD or 2.5" SATA SSD
Maximum Drive Bays with Expansion Unit	36 (RX1225RP × 2)
External Ports
RJ-45 10GbE LAN Port	2
Out-of-Band Management LAN Port	1
USB 3.2 Gen 1 Port	2
Expansion Port	2
Expansion Port Type	Mini-SAS HD
PCIe
PCIe Expansion	2 × Gen4 x8 slot (x8 link)
Appearance
Form Factor (RU)	2U
Size (Height × Width × Depth)	88 mm × 482 mm × 724 mm
Weight	14.5 kg
Rack Installation Support	4-post 19" rack (Synology Rail Kit - )
Others
System Fan	80 mm × 80 mm × 4 pcs
Fan Speed Mode	Full-Speed Mode Cool Mode Quiet Mode
Noise Level	38.8 dB(A)
Power Supply Unit / Adapter	550 watts
AC Input Power Voltage	100 V to 240 V AC
Power Frequency	50/60 Hz, Single Phase
Power Consumption	147.79 watts (Access) 75.73 watts (HDD Hibernation)
British Thermal Unit	503.96 BTU/hr (Access) 258.24 BTU/hr (HDD Hibernation)
Temperature
Operating Temperature	0°C to 35°C (32°F to 95°F)
Storage Temperature	-20°C to 60°C (-5°F to 140°F)
Operating Humidity	8% to 80% RH
Storage Humidity	5% to 95% RH
Warranty
Optional Accessories

Maximum Single Volume Size	200 TB (32 GB memory required) 108 TB
Maximum Internal Volume Number	32
Supported RAID Type	RAID F1 Basic JBOD RAID 0 RAID 1 RAID 5 RAID 6 RAID 10
RAID Migration	Basic to RAID 1 Basic to RAID 5 RAID 1 to RAID 5 RAID 5 to RAID 6
Volume Expansion with Larger HDDs	RAID F1 RAID 1 RAID 5 RAID 6 RAID 10
Volume Expansion by Adding a HDD	RAID F1 JBOD RAID 5 RAID 6
Global Hot Spare Supported RAID Type	RAID F1 RAID 1 RAID 5 RAID 6 RAID 10

Internal Drives	Btrfs
External Drives	Btrfs ext4 ext3 FAT32 NTFS HFS+ exFAT

File Protocol	SMB AFP NFS FTP WebDAV Rsync
Maximum Number of SMB Connections (FSCT-Based)	1,800

Maximum Local User Accounts	2,048
Maximum Local Groups	512
Maximum Shared Folder	512
Maximum Shared Folder Sync Tasks	12

Hybrid Share Folder Number	15

Syslog Events per Second	3,000
Virtualization
VMware vSphere	ESXi 8.0 U2, ESXi 8.0 U1, ESXi 8.0, ESXi 7.0 U3, ESXi 7.0 U2, ESXi 7.0 U1, ESXi 7.0, ESXi 6.7 U3, ESXi 6.7 U2, ESXi 6.7 U1, ESXi 6.7, ESXi 6.5 U3, ESXi 6.5 U2, ESXi 6.5 U1, ESXi 6.5
Microsoft Hyper-V	Windows Server 2025, Windows Server 2022
Citrix XenServer	XenServer 8.4, XenServer 8, Citrix Hypervisor 8.2 LTSR CU1
OpenStack	Cinder

Supported Protocols	SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Supported Browsers	Chrome Firefox Edge Safari
Supported Language	English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文
Synology AI Console
Maximum De-Identification Rate	1,800 words per second

Maximum Number of Users	500
Download Station
Maximum Concurrent Download Tasks	80

Maximum iSCSI Target Number	64
Maximum LUN	128

Free Email Accounts	5
Maximum Number of Users	3,900

Maximum Snapshots per Shared Folder	256
Maximum Snapshots per LUN	64
Maximum Snapshots per System	4,096
Maximum Replication Tasks for Shared Folders	32
Maximum Replication Tasks for LUNs	16
Maximum Replication Tasks per System	32

Default Licenses	2
Maximum IP Cameras and Total FPS (H.264)	1080p: 90 channels, 2250 FPS 3M: 90 channels, 1500 FPS 5M: 90 channels, 900 FPS 4K: 55 channels, 550 FPS
Maximum IP Cameras and Total FPS (H.265)	1080p: 90 channels, 2700 FPS 3M: 90 channels, 2250 FPS 5M: 90 channels, 1500 FPS 4K: 90 channels, 1080 FPS

Maximum Number of Users	3,300
Maximum Number of Hosted Files	25,000,000 (applies to files indexed or hosted by . For file access through other standard protocols, refer to the File Services section above)

Maximum Number of Users	3,200

Recommended Virtual Machine Instances	12
Recommended Virtual DSM Number	12 (including 1 Free License)

Maximum Connections	12
