RX expansion · RX418

Synology RX418 4-bay expansion unit

Name: Synology RX418 4-bay expansion unit
Brand: Synology
SKU: RX418
Price: 1328.00 AUD
Availability: InStock

4-bay 1U rackmount expansion unit for 1U RackStation

$1,328.00inc. GST

Only 1 left

Australian stock, GST tax invoice
Genuine Synology, full local warranty
Dispatched in 1 business day when in stock
Ask a question about this model

Bays: 4

Data sheet and downloads on synology.com

Storage capacity expansion

When the storage capacity on Synology 1U RackStation reaches its limit, Synology expansion unit RX418 provides easy capacity expansion by adding 4 3.5"/2.5" SATA drives to the system. Synology RX418 can also be used as a dedicated local backup destination of Synology 1U RackStation for comprehensive data protection.

Reliable plug-and-play design

Simply connect Synology RX418 to corresponding Synology RackStation and it is ready to use. Drives in the connected Synology RX418 operate as though they were internal to the connected Synology NAS and can be managed directly by Synology DiskStation Manager (DSM), with no additional software installation required.

Green and easy to manage

Award-winning Synology DSM provides an intuitive user interface for easy system management. Drive hibernation can be configured in DSM to take effect automatically when the system has been inactive for a period of time. This not only saves energy but also extends the lifespan of the installed drives.

About the RX418

Synology RX418 delivers an effortless solution for volume expansion and data backup for Synology 1U RackStation by adding 4 additional SATA drive bays on-the-fly. With its short-depth chassis design, RX418 ensures easy installation and deployment in 2-post racks and wall mount racks. Synology RX418 is backed with Synology's 3-year limited warranty. Models supported RS818+, RS818RP+, RS816, RS815+, RS815RP+, RS815. Synology Live Chat available - https://www.synology.com/en-global

Key points

Plug-and-Use Design for Seamless Storage Space Upgrade
Online Volume Expansion
12-Inch Depth to Fit in 2-Post Racks & Wall Mount Racks
Energy-Saving Deep Sleep Mode
Managed from Synology DiskStation Manager (DSM)
Warranty can be extended to 5 years with the purchase of EW201

Specifications

As published by Synology for the RX418. Confirm the latest data sheet before relying on a figure for a tender.

Applied Models
Supports creating volumes across different units	22 series: RS822RP+, RS822+ 21 series: RS1221RP+, RS1221+ 20 series: RS820RP+, RS820+ 19 series: RS1219+, RS819 18 series: RS818RP+, RS818+ 16 series: RS816 15 series: RS815RP+, RS815+, RS815
Supports creating volumes on a single unit only	RS217
Storage
Drive Bays	4
Drive Type	3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD
External Ports
eSATA Port	1
Appearance
Size (Height × Width × Depth)	44 mm x 430.5 mm x 290 mm
Size (Height x Width x Depth) (with server ears)	44 mm x 480 mm x 325 mm
Weight	4.28 kg
Rack Installation Support	4-post 19" rack (Synology Rail Kit - / ) 2-post 19" rack (direct mounting)
Power
Power Recovery	Synchronized with the Synology RackStation
Power Supply Unit / Adapter	100 W
AC Input Power Voltage	100V to 240V AC
Power Frequency	50/60 Hz, Single Phase
Power Consumption	23.26 W (Access) 6.39 W (HDD Hibernation)
British Thermal Unit	79.42 BTU/hr (Access) 21.82 BTU/hr (HDD Hibernation)
Temperature
Operating Temperature	5°C to 35°C (40°F to 95°F)
Storage Temperature	-20°C to 60°C (-5°F to 140°F)
Operating Humidity	8% to 80% RH
Storage Humidity	5% to 95% RH
Others
System Fan	40 mm x 40 mm x 3 pcs
Noise Level	25.1 dB(A)
